Designers and Manufacturers of Solid State Microwave and Millimeter-Wave Components |
 |
 |
 |
| Special Offers - Limited Time / Expires end off 2011 (Alternative Frequency & Powers on request ) |
| Frequency (GHz) |
9-11 |
18-24 | 28-38 | 58-68 |
70-79 | 80-85 | 187-92 |
93-96 | 98-102 |
1108-112 |
| Power (dBm) |
17 |
17 |
17 |
17 |
17 |
17 |
17 |
16 | 11.8 |
10 |
| Center Frequency Fc (GHz) | 10 |
22 |
30 |
61 |
75 |
82 |
90 |
94 |
100 |
110 |
| Bandwidth (MHz) |
5 |
10 |
10 |
100 |
100 |
100 |
100 |
100 | 100 |
100 |
| Bias Voltage ~ |
9.0 |
5.5 |
5.5 |
5.5 |
5.5 |
4.8 |
4.6 |
4.1 | 4.1 |
3.8 |
| Bias Current ~ |
810 |
850 |
650 |
850 |
820 |
820 |
780 |
780 | 780 |
700 |
| Waveguide WR |
90 |
42 |
28 |
15 |
12 |
12 |
10 |
10 | 10 |
10 / 8 |
| 5 to 10 pieces each ( GBP ) |
700 |
900 |
900 |
1300 |
1300 | 1300 |
1400 | 1400 | 1500 |
1500 |
GVS (GNVS) Varactor Tuned oscillators
| Frequency (GHz) | 74-78 |
82-86 |
87-90 |
91-95 |
91-95 |
123457 |
99-101 |
12345678 |
| Power (dBm) | 15 |
15 |
15 | 15 |
13 |
10 |
||
| Center Frequency Fc (GHz) | 76 |
85 |
88 | 94 |
94 |
100 |
||
| Bandwidth (MHz) | 500 |
500 |
500 | 500 |
1000 |
600 |
||
| Bias Voltage ~ | 5.0 |
4.8 |
4.6 | 4.4 |
4.4 |
4.0 |
||
| Bias Current ~ | 810 |
810 |
800 | 750 |
750 |
750 |
||
| Varactor voltage | 0 to +15 |
0 to +15 | 0 to +15 | 0 to +15 |
0 to +15 |
0 to +15 |
||
| Waveguide WR | 12 |
12 |
10 | 10 |
10 |
10 |
||
| 5 to 10 pieces each ( GBP ) | 1450 |
1450 | 1500 | 1500 |
1700 |
2100 |
GW & GM Mechanically Tuned oscillators
| Frequency (GHz) | 9-11 |
50-60 |
60-70 |
70-80 |
80-90 |
90-1004 | 100-105 |
105-110 |
110-115 |
| Power (dBm) | 17 |
17 |
17 |
17 |
17 |
14.8 | 11.8 |
10 |
9 |
| Center Frequency Fc (GHz) | 10 |
55 |
65 |
75 |
85 |
95 |
102 |
106 |
112 |
| Bandwidth (GHz) | 0.5 |
4 |
4 |
4 |
4 |
4 |
4 |
3 |
3 |
| Bias Voltage ~ | 9.0 |
5.8 |
5.5 |
5.3 |
4.8 |
4.4 |
4.2 |
4.0 |
3.8 |
| Bias Current ~ | 810 |
850 |
850 |
850 |
750 |
750 |
750 |
750 |
700 |
| Waveguide WR | 90 |
15 |
15 |
12 |
10 |
10 |
10 |
10 |
10 / 8 |
| 5 to 10 pieces each ( GBP ) |
900 |
2700 |
2700 |
2800 | 2800 |
2900 | 3000 |
3200 |
3300 |
 |
 |
 |
  |
| G (GN) |
GVS (GNVS) |
GW |
G28-I
GN90 & GM90-SMA |
 |
Performance subject to change without notice
